The most pressing tasks of users can be solved thanks to the increased power of the processor. Due to the improvement of the hardware, a significant reserve has been created, which allows maintaining high stability.
Modern solutions in the field of vehicle monitoring are inextricably linked with the ability to work with the CAN bus. Dozens of significant parameters of equipment operation, which do not require additional sensors, are available in the new UMKa302.
To work with CAN, support for the J1939 standard and a custom filter is implemented, which allows you to get all the data of interest from the car you need.
Optionally, simultaneous operation with two CAN buses is available.
All versions of UMKa302 support working with wireless sensors using BLE technology. Information about the fuel level and its temperature will be transmitted with the same accuracy as when using a wired FLS. You can use up to 8 sensors, and if this is not enough, you can supplement the system with classic meters.
Specifications
< table id="loadcontent" border="0" cellspacing="0" cellpadding="0">GNSS receiver channels
Tracking–33, capturing –99
Primary data path
GSM 850/900/1800/1900
Analog/Digital Inputs
2
Pulse/digital inputs
< /div>2
Output (type)
2 outputs, open collector
Interfaces
RS-485, 1 -Wire, Bluetooth
Additional interfaces
RS-232, up to 2 CAN
Black box size
up to 100,000 entries
MicroSD memory size
up to 100,000,000 entries
Number of SIM cards
< /div>2
Control
< /div>USB, SMS, GPRS, Bluetooth
Power
+8... +40 B
Antennas
Built-in or external
Smart power management
>yes
EGTS protocol support
yes
Additional power supply
Optional
Optional
Dimensions (including mounting)
90x71x26mm
Weight no more than g
120
Sheath protection level
IP54
