Benefits:< /h3> - new, improved body;
- in addition to the usual RS-485, RS-232 and BLE interfaces are supported;
- up to 10 sensors can be connected at the same time;
- display up to 10 different screens, the ability to switch between them by simply pressing the touch button;
- it is possible to connect to the device as wired , and wireless sensors;
- configuration using a special mobile application.
Than is this fixture useful?
Allows you to quickly track the actual angle of inclination on special equipment, thereby ensuring safety when working on it.
Minimizes risks during the transportation of goods due to the ability to control the temperature in the refrigerator at any time .
Fuel control in the absence of a regular sensor, or in case of its failure: on diesel locomotives, stationary tanks.
Improve field handling, thereby increasing yield.
Specifications:
| Power supply voltage, V | 9 … 36 |
| Consumed current, not more than mA | 150 |
| 1) Tracker interface 2) Data exchange protocol 3) Data exchange rate | 1) RS-485, RS-232 2) LLS 3) 19200 bps |
| 1) Interface with measuring unit and mobile device 2) Communication protocol data | 1) Bluetooth LE (BLE) 2) Escort I-5 |
| Standard Bluetooth | Bluetooth Low Energy 5 LR coded PHY (central) Bluetooth Low Energy 4 (connection, advertising) | Receiver sensitivity / transmitter power, dBm | -96 / 8 |
| Operating frequency range , GHz | 2.402-2.480 |
| Number of polled sensors, up to pcs. | 10 |
| Maximum number of configurable LLS addresses | 40 |
| Shell protection level according to GOST 14254 | IP65 |
| Protection against electric shock according to GOST 12.2.007.0 | class III |
| Operating conditions: - ambient temperature, °С< br /> - limiting ambient temperature, °С - atmospheric pressure, kPa | - 40 … + 50 - 45… + 55 84 … 106.7 |
| Dimensions, no more than mm | 400 x 70.5 x 22 |
| Weight, no more than kg | 0,3 |
